Polymer Analysis

Mechanics of Solid Polymers--Book Cover
Comprehensive book written
by Veryst's Dr. Jorgen Bergstrom

Veryst provides expert services for product design, manufacturing processes, and failure analysis of polymeric parts and components.  Our expertise includes experimental characterization, computer modeling, and engineering failure analysis.  Much of our work is based on advanced characterization and physically-based computer models to solve industrial problems involving polymer systems.  Veryst has extensive experience modeling polymer materials for finite element analysis and multiphysics applications.

The mechanical response of polymeric materials (rubbers, elastomers, thermoplastics, thermosets, foams, composites, and biomaterials) are characterized by significant nonlinear effects, including:

  • Creep
  • Temperature-dependence
  • Anisotropy
  • Yielding and plastic flow
  • Crazing
  • Aging
  • Composites
  • Large deformations
  • Strain rate-dependence
  • Texture development
  • Stress relaxation
  • Fracture and failure
  • Coupled effects
  • Environmental effects


Some or all of these effects may be active in the intended use of a polymer product.  It is important to understand their influence and impact on the performance and lifetime of the product.

Services include:

  • Analysis of material compositions and structures
  • Experimental testing of the mechanical response under different conditions, including time effects, rate effects, temperature effects, and environmental effects
  • Modeling and predictions of mechanical behavior, including nonlinear effects
  • Fatigue and fracture mechanics analysis
  • Finite element (FE) and multiphysics simulations and predictions of large deformations and complex geometries
  • Analysis of coupled effects



User-Material Subroutines for Finite Element Programs

Veryst also provides advanced finite element user-material subroutines for simulation of complex polymer materials, including:

  • Foams
  • Fluoropolymers
  • Ultra-high molecular weight polyethylene (UHMWPE)
  • Hydrogels
  • Polycarbonate urethane (PCU)
  • Elastomers
  • Thermoplastics
  • Thermoplastic urethane (TPU)
